System specifications
Connection | SourceCon™ interface card slot | |
Inputs | Type | 15 trigger contact inputs (NO or NC) |
Connector | 2 x 8-pin Euro Terminal Block (Pitch – 3.81 mm) | |
Outputs | Type | Balanced stereo line outputs |
Connector | 3-pin Euro Terminal Block (Pitch – 3.81 mm) | |
Level | +8 dB ~ -91 dB | |
Compatible media | Playback | USB memory |
USB HDD (external) | ||
Micro SD card (internal) | ||
Compatible filesystems | FAT16 | |
FAT32 | ||
Supported filetypes | Playback | MP3 |
Ogg Vorbis | ||
AAC | ||
FLAC | ||
WMA | ||
WAV | ||
THD+N (@ 1 kHz) | < 0.07% | |
Crosstalk (@ 1 kHz) | 80 dB | |
Power | Consumption | 1 W |
Product Features
Dimensions | 87 x 34.5 x 114 mm (W x H x D) |
Weight | 0.079 kg |
Mounting | SourceCon™ interface card slot |
Recommended applications
Retail
|
Corporate
|
