| Performance | |
| Frequency Range (-10 dB) | 28 Hz – 125 Hz |
| Maximum Linear SPL1 | 140 dB |
| Maximum SPL2 | 144 dB |
| 1. Measured Maximum Linear SPL at 1m according to AES75 standard using 18dB crest factor M-Noise. 2. Measured Maximum SPL at 1m using burst noise. |
|
| Electronics and Connectors | |
| Nominal Amplifier Power (continuous) | 3600 W |
| Nominal Amplifier Power (peak) | 7200 W |
| Nominal Amplifier Power LF (continuous) | 3 x 1200 W |
| Nominal Amplifier Power LF (peak) | 3 x 2400 W |
| Input Type | Balanced Analog |
| Input Impeadance | 20 kohms |
| Input Sensitivity | 6.2 V (+18 dBu) |
| Audio Signal Input Connector | 1 x Female XLR |
| Audio Signal Loop Thru Connector | 1 x Male XLR |
| Audio/Data Input Connector | etherCON |
| Control | ALMA |
| Audio + Data Loop Thru Connector | etherCON |
| AC Output Connector | powerCON TRUE1 |
| Current Draw 230 V / 115 V | 7.5 /15 A |
| Sampling Rate | 96kHz |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Rigging | Captive Rigging System |
| Finish | ISO-flex Paint |
| Color | Black |
| IP Rating | IP43 |
| Dimensions ( H x W x D ) | 555 x 1.170 x 1.015 mm 21,9 x 46,0 x 40,0 in |
| Net Weight | 125,0 kg ( 275,0 lb ) |
| Components | |
| LF Driver | 18UXN |
| LF Cardioid Driver | 18UXN |
